2 Zone Installation Mixer with 2 Mic_Line Inputs & 6 Stereo Inputs

2 Balanced Mic/Line Inputs on Euroblock Connectors. 6 Stereo or Mono Inputs on Euroblock Connectors. 2 Balanced Mono or Stereo Outputs on Euroblock Connectors. Priority Microphone. Phantom Power Supply on Inputs 1 and 2. Gain and Tone Adjustment on Channels 1 and 2. Gain Adjustment on all Inputs. Mute Contact Possible on Outputs 1 and 2. Assignment of Zones 1 and 2 on each Input ChannelUnit Size: 1U Dimensions: 482 x 44 x 32mm Weight: 9Kg. This installation mixer has 8 input channels- any of these can be routed to either or both of the zone outputs.

The first two input channels have talk over- phantom power- 3 band EQ- all inputs have gain control and mono stereo switch. Settings can be pre-set on the back to eliminate user errors with adjustments to key settings. All inputs are on euro blocks making for a solder and connector free installation. There is a 24v DC power input for a battery back up supply. The mixer has simple layout with easy to use controls- each input has a volume control and two switches to select what zone the input is sent to. Each output has a volume and tone controls.

A good choice for small installations in bars- restaurants and gyms. . audio mixer-installation mixer
