Six Microphone and 2 Line Level Mixer

24V DC Power Option . 6 Switchable Mic Or Line Inputs. 2 Stereo Aux Inputs. Individually Switchable Phantom PowerPower supply:100-240Vac- 50/60Hz (IEC) or 24Vdc (terminals)
Fuse:T1AL 250V (mains) or F500mA (24Vdc)
Inputs : mic/line:6 x balanced XLR
Inputs : aux:2 x L+R RCA
Outputs:L+R XLR- mono 6. 3mm jack- L+R RCA (REC)
Controls:6 x Mic/Line level- 2 x Aux level- Treble- Bass- Master
Input impedance:3.

3k Ohms (mic/line)- 10k Ohms (aux)
Frequency response : mic:20Hz - 18kHz
Frequency response : line:14Hz - 20kHz
Frequency response : aux:10Hz - 23kHz
Input sensitivity : mic:-45dBV
Input sensitivity : aux/line:-10dBV
Signal to noise ratio : mic:55dB
Signal to noise ratio : aux/line:60dB
THD:0. 05%
Dimensions:482 x 130 x 44mm
Weight:1. 43kg
Phantom power:+20Vdc (switchable). Rack-mountable 1U mixer with 6 mic/line inputs and 2 auxiliary inputs. Each mic/line channel has switchable phantom power and input level.

Output connections are stereo XLR- mono jack or REC output on RCA with master bass and treble tone controls. Designed as a master or expansion mixer for installed sound systems and conferences. . mic and mixer-mic set-microphone set
